NXJ wedge aluminum full gold resistant wire clip

◆ Overview

NXJ series wedge-type aluminum alloy tension clamp for 1KV and 10KV and below the overhead insulated aluminum wire (KJLYJ) terminal or end of the tensile section on the tension insulator string, the overhead insulated wire fixed or tightened. Each product is equipped with a different plastic wedge core according to wire specifications.

◆ Specifications and technical parameters

Serial number	he number of product model	1KV overhead insulated conductor		10KV overhead insulated conductor
		Wire size(mm2)	The wire diameter (mm)	Wire size (mm -)	The wire diameter (mm)
1	NXJ-1	162	7.2
		252	8.4
		352	9.8
2	NXJ-2	502	11.2	162	12.6
		702	12.8	252	14.8
		952	14.8	352	15.8
		1202	16.7	502	17.1
3	NXJ-3	1502	18.2	702	18.8
		1852	20.2	952	20.4
		2402	23.0	1202	21.8
				1502	23.0
4	NXJ-4			1852	25.0
4	NXJ-4			2402	27.2
