NLL aluminum full gold resistant clip

◆Overview

NLL series of bolt-type aluminum alloy tension clamp for 10KV and below overhead lines, in the resistance rod fixed aluminum wire or ACSR, for overhead insulated aluminum wire and insulation cover supporting the use of insulation protection Role

◆ Structural features

1. The clip body is made of high strength aluminum alloy

2. Appearance smooth, long service life

3. Easy to install and use

4. No power loss, is energy-saving certified products

◆ Specifications and technical parameters

Serial number	Model	Application of wire	U type screw		A failure load (kN)
Serial number	Model	Application of wire	Number	diameter	A failure load (kN)
1	NLL-1	5.0-10.0	2	12	40
2	NLL-2	10.1-14.0	2	12	40
3	NLL-3	14.1-18.0	3	14	70
4	NLL-4	18.1-23.0	3	14	90
5	NLL-27	12.48-23.0	4	16	90
6	NLL-5L	23-29	3	16	90
7	NLL-6	25.9-32.67	5	16	100

Serial number	Model	Application of wire	U type screw		A failure load (kN)
Serial number	Model	Application of wire	Number	M	A failure load (kN)
1	NLD-2L	35-95	2	M16	30
2	NLD-2L	120-150	2	M16	40
3	NLD-2L	185-240	2	M18	50
4	NLD-2L	240-300	2	M18	70
