FHJ type lightning protection (anti-arc) clip

◆Overview

Multi-function overhead insulated cable lightning protection clip, is a protection for 1-10 kV overhead insulated cable in the insulator support from the lightning strikes the power of gold. It can also be used for earthing protection and inspection of insulated cables. Is 10KV overhead insulated cable over-voltage limiter, when the lightning over-voltage occurs, the lightning protection clamp between the two ends of the voltage does not exceed the specified value, so that electrical equipment from over-voltage damage; lightning over-voltage, Quickly returned to normal state.

◆Technical parameters and selection table

Parameters and Applicable Range of 1KV / 10KV Overhead Insulated Conductor

Serial number	Model and specification	Cable cross-sectional area mm2	Conductor diameter mm	Insulated cable diameter		Use conditions
Serial number	Model and specification	Cable cross-sectional area mm2	Conductor diameter mm	Thin	Universal type	Use conditions
1	KYFH10-50/150(KYFH10-1)	50	8.3	13.8	15.1	1. The ambient temperature is not high +50 DEG C, not less than 40 DEG C, the altitude of 2 1000m is not more than the power supply frequency of 50-60Hz: the maximum wind speed of is not more than 5 35m/S and the area of the earthquake is less than 8 degrees
		70	10.0	15.0	16.8
		95	11.6	16.6	18.4
		120	13.0	18.0	19.8
	KYFH10-185/240(KYFH10-2)	150	14.6	19.6	21.4
		185	16.2	21.2	22.6
		240	18.4	23.4	24.8

◆combination with different insulators
